Up to -/30/30 fi re resistance in accordance with criteria of BS 476: Part 22: 1987 and BFTC 95/18
- Door frame 136mm x 69mm thick of solid meranti wood
- PROMATECT®-H core 12mm thick
- Decorative plywood facing 4mm thick bonded to PROMATECT®-H core
- Top rail, mullions transoms and door stiles 100mm wide x 54mm thick solid meranti wood
- Bottom door rail 200mm wide x 54mm thick
- PROMASEAL® LFCSK Intumescent Seal 10mm wide x 2mm thick, fi tted along door jambs and perimeter edges of door
- Glazing beads 38mm x 20mm bonded to door leaf framing
- Intumescent glazing seal (type of glazing seal is dependent on type of glass installed)
- Georgian wire glass 6mm thick
- Steel butt hinge 100mm fi xed into door frame and leaf using 38mm No.10 wood screws
- Union 2.5″ mortise latch with aluminium level handles
Up to -/60/60 fi re resistance in accordance with criteria of BS 476: Part 22: 1987 and IS: 3809: 1979 and CNP-2150
- MDF door frame 120mm x 70mm thick
- PROMATECT®-H core 15mm thick
- M 10mm thick coated with PROMASEAL® AN Acrylic Sealant
- Plywood 4mm thick with 1mm paint or lamination on both sides
- Perimeter framing of medium meranti wood 35mm wide x 34mm thick
- PROMASEAL® LFCSK Intumescent Seal 10mm wide x 2mm thick
- PROMASEAL® AN Acrylic Sealant to seal gaps between PROMATECT®-H core and door stiles
- Stainless steel ball bearing hinges 304 grade 100mm x 75mm x 2.5mm
- Stainless steel latch or L drop
Up to -/120/120 fi re resistance in accordance with criteria of BS 476: Part 22: 1987 and CNP-0253
- Red meranti door frame 150mm x 75mm thick
- PROMINA®-60 board 9mm thick
- Mineral wool infi ll 30mm thick x 96 kg/m3 with fi re rated PROMASEAL® Acrylic Sealant 1mm thick coated on both sides
- Decorative plywood facing 3mm thick
- Red meranti hard wood stile and rails to door leaf 100mm x 30mm thick (density ≥ 650 kg/m3)
- Teak wood lippings 10mm thick
- PROMASEAL® LFCSK Intumescent Seal 20mm x 2mm thick on three sides of leaf
- PROMASEAL® LFCSK Intumescent Seal 10mm x 2mm thick on head and jambs of frame
- Stainless steel hinges
- Mortise latch locking system (ME 60 IR)
Up to -/60/60 fi re resistance in accordance with criteria of BS 476: Part 22: 1987 and BFTC ASS06/03
- Double rebated metal door frame 140mm x 65mm x 1.2mm thick
- PROMINA®-HD board 6mm thick
- Mineral wool infi ll 25mm thick x 80 kg/m3
- Decorative plywood facing 3.2mm thick
- Internal framing 67mm x 26mm thick medium meranti or similar hardwood, nominal 650 kg/m3 density
- Hardwood timber lippings 13mm thick fitted on the perimeter of the door leaf
- PROMASEAL® LFCSK Intumescent Seal 20mm x 2mm thick fi tted centrally to grooves within the lipping at both vertical edges and top edge of door
leaf - Stainless steel hinges of size 127mm X 75mm X 2.5mm
- Known tested brand door closer
- Lockset with 70mm backset
- Sand or cement mortar infi ll
- Frame fi xings of nominal 500mm centres
Up to -/120/120 fi re resistance in accordance with criteria of BS 476: Part 22: 1987 and Report CBRI 212 (1)/FR/2003
- Steel door frame 160mm x 60mm x 1.6mm thick
- PROMINA®-60 board 9mm thick
- Fire rated insulation ceramic fi bre blankets 30mm thick x 96 kg/m3 with PROMASEAL® Acrylic Sealant 1mm thick on both sides
- Decorative plywood facing 3mm thick
- Red meranti hard wood stile and rails to door leaf 100mm x 30mm thick (density ≥ 650 kg/m3)
- Teak wood lippings 55mm x 10mm
- PROMASEAL® LFCSK Intumescent Seal 20mm x 2mm thick on three sides of leaf
- PROMASEAL® LFCSK Intumescent Seal 10mm x 2mm thick on head and jambs of frame
- Stainless steel hinges fi xed using 35mm x No.8 screws into door leaf and door frame
- Aluminium knob set
- Sand or cement mortar infill
